AC Drive – 5.5 kW (7.5 HP)

Input: 480V AC, 3 Phase, 50-60 Hz
Output: 13A
Enclosure Rating: IP20
Mounting: Panel Mount
Safety Features: Safe Torque-Off PID-SIL2 Cat 3
Control Features: V PerHz, Sensorless Vector-Closed Loop Vector, Permanent Magnet Motor Control
Type: IGBT with Brake

The 5.5 kW (7.5 HP) AC Drive is engineered to deliver efficient, high-performance motor control for a wide range of industrial applications. This drive offers excellent versatility and reliability, supporting safe and precise motor operation for applications requiring high-torque output and tight control.

---

Key Features:

• Power Rating: 5.5 kW (7.5 HP)

• Input Voltage: 480V AC, 3 Phase, 50-60 Hz – compatible with industrial power systems

• Output Current: 13A – providing ample current for demanding motor applications

• Enclosure Rating: IP20 – for installation in dry, protected environments

• Mounting: Panel Mount – designed for easy integration into control panels or cabinets

• IGBT Technology: With Brake IGBT for precise and efficient braking performance

• Motor Control:

  • V PerHz Control: For standard motor applications requiring basic control

  • Sensorless Vector Control: Provides precise control without the need for feedback sensors

  • Closed Loop Vector Control: Offers high-performance, high-torque control for dynamic applications

  • Permanent Magnet Motor Control: Efficiently operates permanent magnet motors for better energy savings and performance

• Safety Features:

  • Safe Torque-Off (STO): PID-SIL2 Cat 3 certified, ensuring safe operation with the prevention of unwanted motion

  • PID Control: Provides precise control of motor speed and torque, ideal for industrial automation systems

---

Applications:

• Industrial Automation

• Pumps, Fans, and Compressors

• Conveyor Systems

• Robotics

• Machinery with Dynamic Torque Requirements

---

This AC Drive is an ideal choice for applications requiring reliable, high-efficiency motor control in a compact panel-mounted solution. With built-in safety features, flexible control options, and the ability to operate permanent magnet motors, it meets the demands of modern industrial systems.
