AC Drive – 0.75 kW (1 HP)

Input: 480V AC, Three Phase, 50-60 Hz
Output: 2.3A
Enclosure Rating: IP20
Mounting: Panel Mount
Safety Features: Safe Torque-Off PID-SIL2 Cat 3
Control Features: V PerHz, Sensorless Vector-Closed Loop Vector, Permanent Magnet Motor Control
Type: IGBT with Brake

The 0.75 kW (1 HP) AC Drive is a compact, high-performance motor controller designed for a variety of industrial applications. This drive provides precise control over motor speed and torque, making it ideal for applications such as fans, pumps, conveyors, and other equipment that require reliable motor control in a safe and efficient manner.

---

Key Features:

• Power Rating: 0.75 kW (1 HP) – Ideal for low to medium-power motor control applications

• Input Voltage: 480V AC, Three Phase, 50-60 Hz – Suitable for industrial environments with three-phase power supply

• Output Current: 2.3A – Sufficient for operating motors in the 0.75 kW range

• Enclosure Rating: IP20 – Designed for installation in dry, controlled environments

• Mounting: Panel Mount – Can be easily integrated into control panels and electrical cabinets

• IGBT Technology: With Brake IGBT for enhanced braking performance and precise control

• Motor Control:

  • V PerHz Control: Standard control for motors with a linear relationship between voltage and frequency

  • Sensorless Vector Control: Provides precise motor control without the need for feedback sensors

  • Closed Loop Vector Control: Ensures high-torque performance and dynamic speed control in demanding applications

  • Permanent Magnet Motor Control: Optimizes operation of permanent magnet motors for better energy efficiency and performance

• Safety Features:

  • Safe Torque-Off (STO): PID-SIL2 Cat 3 certified, ensuring safety by preventing unintended motor movement

  • PID Control: Allows for precise control of motor speed and torque, ideal for process and automation applications

---

Applications:

• Industrial Automation

• Fans, Pumps, and Compressors

• Conveyor Systems

• Small Machinery with Dynamic Torque Requirements

• Robotics and Automation Systems

---

This 0.75 kW (1 HP) AC Drive provides excellent performance in applications where space is limited but precise motor control and safety are critical. With the ability to operate permanent magnet motors efficiently, integrate seamlessly into industrial automation systems, and offer enhanced safety features, this drive meets the demands of a wide range of applications.
